TRANSPORT BELT-OVER

2.15-1 Contact Customer Care at 1.844.4HYTROL

SL

Steel Belt Slat Conveyor

The model SL Steel Belt Slat conveyor provides lasting, dependable performance. Can be used to convey hot, oily parts or items through heat drying processes. Can also be used for assembly line and production operations. 5 Bed Widths Energy Efficient Motor with AC Variable Speed Controller Rugged-All Steel Construction Modular Construction Roller Chain Reduces Friction Adjustable SLS-Type Floor Supports Available Size To Order Overall Length "A" Bed Length "L" Belt Width 28" 31" 37" 43" 49" Bed Width 33" 36" 42" 48" 54" 9' - Weights (lbs.) 1692 1773 1936 2099 2262 14' 5' 2184 2291 2506 2721 2936 19' 10' 2677 2809 3076 3343 3610 24' 15' 3169 3327 3646 3965 4284 29' 20' 3662 3845 4216 4587 4958 39' 30' 4647 4881 5357 5831 6306 49' 40' 5632 5917 6497 7075 7654 59' 50' 6617 6954 7638 8319 9003 69' 60' 7602 7990 8778 9563 10351 79' 70' 8587 9026 9918 10807 11669 All weights in catalog are conveyor weights only. Accessories, crating, etc., are not included.

"Y"

25" MINIMUM ELEVATION 1-1/4" DRIVE SPROCKET SLAT RETURN 48" OVERALL LENGTH "A" BED LENGTH "L"

"X"

ACCESS PANEL OPTIONAL SLS SUPPORT SHOWN TAIL SPROCKET TAKE-UP 60"

SECTION X-X

OVERALL BED WIDTH SLAT WIDTH 2-1/2" 1/4" 1-1/2" 2-1/4" BUTT COUPLING STEEL SLAT 2" DIA. ROLLER CHAIN RETURN BED SPACER 17"

OVERALL BED WIDTH

15-7/8" CHAIN GUARD GEAR REDUCER STEEL SLAT 1-1/4" 3-7/16"

SECTION Y-Y

OTHER STANDARD COLORS Conveyor shown in Standard Gray.
