PALLET HANDLING CHAIN DRIVEN LIVE ROLLER

7.3-1 Contact Customer Care at 1.844.4HYTROL The heavy design of the 25-CRR allows it to be used for conveying higher load capacities such as loaded pallets and drums. Chain driven rollers make it ideal for conveying oily parts in bottling and steel industries. 15 Bed Widths Center Drive Reversible Chain Driven Rollers Adjustable HSN-Type Floor Supports Available Conveying Surface 15 3/4" 17 3/4" 19 3/4" 21 3/4" 23 3/4" 27 3/4" 29 3/4" 33 3/4" 35 3/4" 39 3/4" 43 3/4" 47 3/4" 51 3/4" 57 3/4" 63 3/4" Between Rail Width 19" 21" 23" 25" 27" 31" 33" 37" 39" 43" 47" 51" 55" 61" 67" Overall Frame Width 22 1/4" 24 1/4" 26 1/4" 28 1/4" 30 1/4" 34 1/4" 36 1/4" 40 1/4" 42 1/4" 46 1/4" 50 1/4" 54 1/4" 58 1/4" 64 1/4" 70 1/4" *4" Centers 10' OAL No. 40 Chain 722 750 778 806 834 890 918 974 1002 1058 1114 1170 1226 1310 1394 Per Foot 61 64 67 70 73 79 82 88 91 97 103 109 113 124 133 5" Centers 10' OAL No. 50 Chain 638 666 694 721 749 804 823 887 915 970 1026 1081 1136 1219 1302 Per Foot 54 57 60 63 66 72 75 81 84 90 96 102 108 117 126 6" Centers 10' OAL No. 60 Chain 582 610 638 666 694 750 778 834 862 918 974 1030 1086 1170 1254 Per Foot 49 52 55 58 61 67 70 76 79 85 91 97 103 112 121 7 1/2" Centers 10' OAL No. 60 Chain 526 554 582 610 638 694 722 778 806 862 918 974 1030 1114 1198 Per Foot 46 49 52 55 58 64 67 73 76 82 88 94 100 109 118 Conveying Surface 15 3/4" 17 3/4" 19 3/4" 21 3/4" 23 3/4" 27 3/4" 29 3/4" 33 3/4" 35 3/4" 39 3/4" 43 3/4" 47 3/4" 51 3/4" 57 3/4" 63 3/4" Between Rail Width 22" 24" 26" 28" 30" 34" 36" 40" 42" 46" 50" 54" 58" 64" 70" Overall Frame Width 25 1/4" 27 1/4" 29 1/4" 31 1/4" 33 1/4" 37 1/4" 39 1/4" 43 1/4" 45 1/4" 49 1/4" 53 1/4" 57 1/4" 61 1/4" 67 1/4" 73 1/4" 3 3/4" Centers 10' OAL No. 60 Chain 750 778 806 833 861 916 944 999 1027 1083 1137 1193 1249 1332 1415 Per Foot 63 68 71 74 77 83 86 92 95 101 107 113 119 128 137 3 in. RC Chain Guard (Both Sides) Conveying Surface 15 3/4" 17 3/4" 19 3/4" 21 3/4" 23 3/4" 27 3/4" 29 3/4" 33 3/4" 35 3/4" 39 3/4" 43 3/4" 47 3/4" 51 3/4" 57 3/4" 63 3/4" Between Rail Width 22 1/4" 24 1/4" 26 1/4" 28 1/4" 30 1/4" 34 1/4" 36 1/4" 40 1/4" 42 1/4" 46 1/4" 50 1/4" 54 1/4" 58 1/4" 64 1/4" 70 1/4" Overall Frame Width 25 1/2" 27 1/2" 29 1/2" 31 1/2" 33 1/2" 37 1/2" 39 1/2" 43 1/2" 45 1/2" 49 1/2" 53 1/2" 57 1/2" 61 1/2" 67 1/2" 73 1/2" 3" Centers 10' OAL No. 60 Chain 862 890 918 946 974 1030 1058 1114 1142 1198 1254 1310 1366 1450 1534 Per Foot 72 75 78 81 84 90 93 99 102 108 114 120 126 135 144 3 in. RC Chain Guard (One Side) Conveying Surface 17 3/4" 19 3/4" 21 3/4" 23 3/4" 25 3/4" 29 3/4" 31 3/4" 35 3/4" 37 3/4" 41 3/4" 45 3/4" 53 3/4" 59 3/4" 63 3/4" 65 3/4" Between Rail Width 22" 24" 26" 28" 30" 34" 36" 40" 42" 46" 50" 58" 64" 68" 70" Overall Frame Width 25 1/4" 27 1/4" 29 1/4" 31 1/4" 33 1/4" 37 1/4" 39 1/4" 43 1/4" 45 1/4" 49 1/4" 53 1/4" 61 1/4" 69 1/4" 71 1/4" 73 1/4" 3" Centers 10' OAL No. 40 Chain 750 778 806 833 861 916 944 999 1027 1083 1137 1193 1249 1332 1415 Per Foot 63 68 71 74 77 83 86 92 95 101 107 113 119 128 137 All weights in catalog are conveyor weights only. Accessories, crating, etc. are not included. Note: Add 1 3/8 in. to OAL for chain guard end caps on 4 in. centers only. For 3 in. RC Chain Guard (both sides), add 3 in. to OAL for chain guard end caps. #40 chain reduces total conveyor capacity. Consult factory.

Conveyor shown with optional floor supports.

25-CRR

Chain Driven Live Roller Conveyor

TECHNICAL MANUAL
