TRANSPORT LIVE ROLLER
9.2-2 Contact Customer Care at 1.844.4HYTROL BED - Roller bed with 1.9 in. dia. roller x 16 ga. galvanized tube. Mounted in 6 1/2 in. 12 ga. powder-painted formed steel channel frame. SLAVE-DRIVEN - Spurs are driven from power supply of model 190-E24 conveyor. 45-degree spur has (1) 24VDC motor with integrated motor control card, 30-degree spur has one 24VDC motor with integrated motor control card on 12 in. to 16 in. OAW, and 2VDC motor with integrated motor control card on 18 in. to 42 in. OAW. Motors mounted on the inside of the B.R. SLAVE O-RING - 3/16 in. dia. polyurethane o-ring from drive spool to tread roller. BEARINGS - Pre-lubricated ball bearings in tread rollers. SPLICE PLATES - Standard for connecting to 190-E24. CAPACITY - See Load Capacity Chart. FLOOR SUPPORTS - Supplied as optional equipment.
190-E24SS
Standard Specifications Optional Equipment
FLOOR SUPPORTS - MS Type floor supports are available with a wide range of adjustment. Specify top of belt or roller elevation. One support required at every bed joint and ends of conveyor. Holes in feet for lagging to floor. Knee braces recommended above MS-6 support. HIGH-SPEED DRIVE SPOOL - Provides a speed range of 50 to 200 FPM Capacity affected with speed change. DRIVE - Motors mounted on the inside of the frame channel. GUARD RAILS - Adjustable Universal Channel Guard Rail, fixed channel or type A or B angle. Note: If product comes in contact with guard rails, product flow will be affected. POLY-TIER SUPPORTS - 36 in. to 120 in. support heights in 6 in. increments. Knee braces supplied. CEILING HANGER - 5/8 in. dia. x 8 ft. long unplated rods fully threaded. Other lengths and galvanized rods available. MOTOR AND SEPARATE CONTROL CARD - Available with 3 Amp setting. Load Capacity Chart Overall Length 190-E24SS Capacity Per Spur 45 30 21" 65 - 36" 111 - 48" 148 - 30" - 92 54" - 166 75" - 231 Between Rail Width Overall Frame Width "A" "B" Weights (lbs.) 45 30 45 30 45 30 15" 18" 36" 54" 32" 41" 193 241 21" 24" 36" 54" 41" 53" 209 258 27" 30" 36" 54" 50" 65" 224 276 33" 36" 48" 75" 59" 77" 240 393 39" 42" 48" 75" 68" 89" 256 310 All weights in catalog are conveyor weights only. Accessories, crating, etc., are not included.
